| Place of Origin: | Made In China |
| Brand Name: | SHELOK |
| Certification: | CE |
| Model Number: | XY-2006B |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | $840 ~ $1205/pc |
| Packaging Details: | Water Pressure Balance Load Cell Test Equipment Standard export carton packing or can customized |
| Delivery Time: | 3 ~ 7 Working Days After Payment |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000pcs/Month |
| Item: | Liquid Pressure Gauge Calibrator Pressure Calibration Pump | Pressure Range: | -0.095~0~60MPa |
|---|---|---|---|
| Work Temperature: | -20 To 50℃ | Diemnsion: | 290 Mm * 150 Mm * 110 Mm |
| Weight: | 3.5kg | Application: | Produce Pressure |
| Medium: | Pure Water Or 46# Hydraulic Oil | Thread: | M20*1.5(2PCS) |
| Min Adjustment: | 10KPa | OEM: | Yes |
XY-2006A Portable air pressure source manually is at present our country in metrological verification or check in the industry,Widespread adoption of dead weight tester or desktop pressure source,electric pressure calibration machine, etc,These products are generally large,Go to the scene is not convenient to carry,but portable products abroad use pliers type.Pressurized laborious,complex operation Combined with the above reasons,My company recently developed a easy to carry, simple structure and easy operation Portable air pressure source manually XY-2006A.
pressure range (0.1 ~ 0 ~ 60) MPa
Size: 270 mm * 150 mm * 150 mm
Adjust the fineness of: 0.1 kPa
Weight:less than 2kg.
Simple structure, easy operation.
Easy to carry, not easy to leak, maintenance is convenient.
Not afraid dirty, not afraid.
Can produce negative pressure (0.1 ~ 6 mpa)
Y039: 0~1.6MPa
Stability :0.05%
Type :Pneumatic pressure
Y060: 0~25MPa
Stability :0.05%
Type :Hydraulic pressure
Y061: -0.08~0MPa
Stability :0.05%
Type :Pneumatic pressure
YFP-16: -0.088~1.6MPa
Stability :0.05%
Type :Pneumatic pressure
YFP-16: -0.088~2.0MPa
Stability :0.05%
Type :Pneumatic pressure
YFP-16: -0.088~2.5MPa
Stability :0.05%
Type :Pneumatic pressure
Range: (-0.1~060)MPa
Type :Hydraulic pressure
Range: 0-6/0-60MPa
Type :Hydraulic pressure
Range: 0-160MPa
Type :Hydraulic pressure
