| Place of Origin: | Made In China |
| Brand Name: | SHELOK |
| Certification: | CE |
| Model Number: | XY-6/XY-60 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | $265 ~ $295/pc |
| Packaging Details: | Water Pressure Balance Load Cell Test Equipment Standard export carton packing or can customized |
| Delivery Time: | 3 ~ 7 Working Days After Payment |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000pcs/Month |
| Product Name: | XY-60 Pressure Gauge Calibration Instrument | Pressrue Range: | 0~60MPa |
|---|---|---|---|
| Pressure Type: | Pressure Type | Fine Adjustment: | 10Kpa |
| Medium: | Oil Or Water |
Pressure gauge calibration also known as a pressure gauge calibration pump,The pressure gauge calibrator is movement of the piston rod pressure increases,So as to achieve the aim of compression.
Pressure gauge calibration device is used for testing the pressure source of general pressure gauge, pressure test can reach 60 MPA, inspection vacuum degree can reach -0.08 MPA.
In laboratory or measuring room generally fit precision pressure gauge (high precision can reach 0.25 magnitude) to detect the ordinary pressure gauge (precision is 1.6 or 2.5).
Parameter XY-60 pressure gauge calibration instrument:
| model number | range | medium |
| XY-6 | -0.082-6MPa | Transformer oil |
| XY-60 | 0-60MPa | Medicinal castor oil |
| XY-80 | 0-80MPa | Medicinal castor oil |
| range | 0~6Mpa | 0~60Mpa |
| vacuum | -0.088~0 Mpa | ----- |
| connector | M20×1.5(M14×1.5) | M20×1.5(M14×1.5) |
The minimum adjustable range: 0.1Mpa
Volume: 350 * 230 * 180mm
Weight: 15kg
Standard export carton packing.
3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.
Q:How long will you reply me?
A:We will contact you as soon as possible but within 12 hours
Q: Can I get some samples?
A: Yes, Sample order is available for quality check and market test. But you have to pay the express cost.
Q: How soon can you arrange your production?
A: Once getting your product confirmation and receiving the prepayment, the production will be started immediately.
Q: What's delivery time?
A: It usually takes about 3-5 working days for small order and 10-15 days for big order.
Q:How do you control your quality ?
A: Three inspection steps(of original, production, and finished goods) + good warranty service(1 year free to change a new one without any human damage factors).
Q: What certificates do you have ?
A:ISO9000, CE, Explosion-proof certification, RoHs ready. And before the delievry of goods, quality and safety inspection certification issued by third parts also can be offered.
Q:Could I visit your factory?
A:Very welcome! Fly to Xian Yang air port. It was a big pleasure for us.
Q: What's your warranty terms?
A: We offer 12 months warranty time.
Q:can you provide OEM & Customized service?
A:Yes, OEM and ODM are both available, we have the professional R&D dept which can provide professional solutions for you.
