| Place of Origin: | Made In China |
| Brand Name: | SHELOK |
| Certification: | CE |
| Model Number: | FDM-1 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | $1150.00 ~ $2175.00 |
| Packaging Details: | Air Pressure Relief Valve, Back Pressure Regulator, Pressure Reducing Valves Standard export package |
| Delivery Time: | 3 ~ 7 Working Days After Payment |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000pcs/Month |
| Product Name: | Liquid Density Meter Density Gauge | Accuracy: | 0.001 G / Cc, With A Resolution Of 0.0001 G / Cc |
|---|---|---|---|
| Power Supply: | 24VDC | Output: | 4-20 MA 4-wire ( 2-wire System Can Not Be Used) |
| Density Range: | 0-3 G / CM3 (3 /2.5/ 2 /1.5/ 1) |
Fork sensors ---------- one pair fork ceramic chip
A piezoelectric ceramic is responsible for collecting vibration
The fork is always vibrate in the resonant frequency of vibration
Fork in different densities ,the resonance frequencies was different,.according to the relationship between the different vibration and density to calculate the density
The resonance frequency of the tuning fork is between 1600-2400
The higher the frequency the smaller density.
Features of Liquid density meter density gauge :
1. Adopt Germany piezoelectric ceramic chip, with gold plated process to increase the oxidation resistance of ceramic chips, also can longer service life of density meter.
2. Fork vibration original chip adopt Japanese made high performance original chips, Built-in 24 AD converter, frequency identifying accuracy to be 0.01HZ, to warranty 3.the sensitivity and precision of the meter.3.Fork density calibration adopts national density standard solution, to ensure the source and accurate of density.
4.The current circuit is independent of fork vibration circuit, there is isolating anti-interference inner, reducing the influence to instrument from disturb.
5. There is set density three point quick calibration, range adjust, current calibration etc function, to meet on-site working demands.
Applications of Liquid density meter density gauge:
1.Application for high precision density measuring, mainly used in power plant.
2.Can not be affected by temperature, pressure and flow rate, there are few factor that can affecting measuring accuracy.
