| Place of Origin: | Made In China |
| Brand Name: | SHELOK |
| Certification: | CE |
| Model Number: | MF4001 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | USD215 ~ USD245/pc |
| Packaging Details: | RS485 Output Mass Digital Air, Gas Flow Sensor Standard export carton packing or can customized |
| Delivery Time: | 3 ~ 7 Working Days After Payment |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000pcs/Month |
| Product Name: | Hydrogen Oxygen Nitrogen Argon Gas Flow Meter | Maximum Flow: | 30,100,200,500,1000sccm |
|---|---|---|---|
| Accuracy: | ±(1.5+0.5FS)% | Repeatability: | ±0.25% |
| Zero Output Drift: | ±30m V | Working Power: | 3.0~3.6VD C ,20m A |
| Display Resolution: | 0.01sccm | Maximum Flow Pressure Loss: | 350Pa |
| Maximum Working Pressure: | 0.5MPa | Operating Temperature: | -10~55℃ |
MF4001 series gas mass flow meters are specially designed for measuring various types of small flow gases and process control . This series of flow meters uses micro Electromechanical system (M EM S? Flow sensor chip for the production of various types of clean gas body. Unique packaging technology enables it to be used in various pipe diameters, low cost, easy installation, no needs temperature and pressure compensation, which can replace traditional flow meters with volumetric or differential pressure.
The sensor chip uses thermal mass flow metering, eliminating the need for temperature pressure compensation, ensuring flow
Gauge high-precision measurement
Multi-sensor integration on a single chip, greatly improving the range ratio of the flow meter
High stability at zero
Full scale high stability
Full scale high accuracy and excellent repeatability
Low power consumption, low pressure loss
Fast response time
