| Place of Origin: | Made In China |
| Brand Name: | SHELOK |
| Certification: | CE |
| Model Number: | NRL809 |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | $35~$125/pc |
| Packaging Details: | Factory High Quality Digital Temperature and Humidity Data Logger Standard export carton packing or can customized |
| Delivery Time: | 3 ~ 7 Working Days After Payment |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000pcs/Month |
| Product Name: | High Temperature Radar Level Detector Non-contact Radar Level Meter | Range: | 30m |
|---|---|---|---|
| Medium Temperature: | -40~250℃ | Process Connection: | Flange,thread |
| Application: | Temperature-resistant, Pressure-resistant, Slightly Corrosive Liquid | Accuracy: | ±3mm |
| Frequency: | 26GHz | Explosive-proof Grade: | ExibIICT6Gb |
| Ingress Protection: | IP67 | Signal Output: | 4-20mA/HART(2 WIRES/4 WIRES)RS485 |
oem krohne radar level detection meter sensor
Very short microwave pulses with very low emission energy are transmitted and received through antenna systems.Radar waves travel at the speed of light.The running time can be converted into a level signal by the back of the electronic component.A special time extension method ensures stable and accurate measurements in a very short time.
Even in the presence of spurious reflection, the latest microprocessing technology and our unique pulse-software can accurately analyze the object position echo.
.
Working conditions:
The temperature can be extended to (-40-400) degrees through different components, such as: air cooling device, water cooling device, scavenging device. The pressure can be extended to 4000KPa with different pressure sealing components
Specification of cement radar level meter microwave radar level sensor oem radar level gauge
Specification of oem krohne radar level detection meter sensor
Dimension of oem krohne radar level detection meter sensor
Application of oem krohne radar level detection meter sensor
Petroleum
Petrochemical, oil production plants, chemical plants, coking plants and other measuring media: crude oil, light oil, natural gas, methanol, ethanol, ammonia, benzene, polyphenylene, ester, water vapor, liquid carbon dioxide, paint, turpentine, pulp
Power industry
Measuring medium for power plant: raw coal bin, pulverized coal bin, fly ash bin, chemical water
Iron and steel industry
Measuring medium for steel mills: limestone, coking coal, cold return ore, raw material bin, powder bin, coal ash bin, chemical water
Cement factory
Clinker storehouse, powder storehouse, raw coal storehouse
Feature of oem krohne radar level detection meter sensor
Independent of temperature and pressure
Microwave operation is almost unaffected by ambient temperature and pressure, so radar sensors are very suitable for complex process conditions.Process pressure from vacuum to 40bar, process temperature -40~400°C, absolutely no problem with the measurement.
It is not affected by the characteristics of the measured medium
Changing the composition of the measured medium or changing the whole medium will not affect the measurement results.No redebugging is required
Compatible line applications for different scenarios
SLK-806 series of radar sensors can be used for any application.We can provide different antennas, thus generating different emission angles, measuring ranges and measuring characteristics.Correct instrument selection depends on application conditions.
Easy service maintenance
SLK-806 is easy to service and maintain due to its non-contact measurement.
