| Place of Origin: | Made In China |
| Brand Name: | SHELOK |
| Certification: | CE |
| Model Number: | TUF-2000H |
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | USD315 ~ USD435/pc |
| Packaging Details: | RS485 Output Mass Digital Air, Gas Flow Sensor Standard export carton packing or can customized |
| Delivery Time: | 3 ~ 7 Working Days After Payment |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 10000pcs/Month |
| Product Name: | Chemical Flow Meter | Accuracy: | Better Than 1% |
|---|---|---|---|
| Output: | RS-232/OCT Output | Dimension: | 220mmx92mmx32mm |
| Repeatability: | 0.2% | S Type Sensor: | 15~100mm |
| M Type Sensor: | 50~700mm | L Type Sensor: | 300~6000mm |
| Weight: | 1.5kg | Flow Rate: | 0.01/s ~±32m/s |
| ·4 Line large-screen LCD ·High accuracy measuring ·Wide measuring range ·Small and light ·RS-232 |
 |
| Repeatability | Better than 0.2% |
| Accuracy | ±1% of reading at rates>0.2 mps |
| Linearity | 0.5% |
| Velocity | ±32 m/s |
| Totalizer | 7-digit totals for net, positive and negative flow respectively |
| Liquid Types | Virtually all liquids |
| Security | Setup values Modification Lockout. Access code needs unlocking |
| Response Time | 0-999 seconds, user-configurable |
| Signal output | Non-isolation RS232(FUJI extension protocol), one channel isolation OCT output |
| Transducer Cord Length | Standard 2x10 meters, optional 2x 500 meters |
| Power Supply |
3 AAA Ni-H built-in batteries. When fully recharged it will last over 12 hours of operation. |
| Case Size |
100x66x20mm |
| Data Logger |
Built-in data logger can store over 2000 lines of data Housing Material ABS |
| Handset Weight |
514g (1.2 lbs) with batteries |
The ultrasonic chemical flow meter can be used to measure ultra-pure liquids,potable water,chemicals,raw sewage,reclaimed water,cooling water,river water,plant effluent,etc.
